V-Show New Upgrade 8 ports: Art-Net sACN, DMX 512 and RDM Console

About this item:

This unit supports protocols. It supports 8 ArtNet universes, totaling 4096 channels. It has two RJ45 ports and eight 3-pin DMX ports, all with 100% electrical isolation.For all kinds of application on TV shows, stage lighting,

 pubs etc.

Features:

l Supports 8 ArtNet universes, total 4096 channels.

l Serial connection possible, which can control 32768 universes, a total of 16777216 channels

l Ethernet I/O based on high speed switch, without linking delay.

l Supported protocols: Art-Net, sACN, DMX 512 and RDM.

l It allows to configure parameters through a web browser

l It is used for extending the DMX output port of Tiger touch and MA Console.

l The 8 DMX ports can all be configured as inputs or outputs.

l Adjustable DMX frames rate (Up to 40 Hz/sec)

l DMX output can be set to one of SINGLE, HTP, LTP mode

l When there is no signal at the DMX Output port, you can choose one of the methods as HOLD, ZERO and OFF.

l DMX ports:3 pins XLR (Option: 5 pins XLR ).

l 100% electrical isolation between all in/outputs: problems on 1 port will not influence the other ports.

l TFT display shows parameters.

l LED indicators for each input and output.

l Wide input stable electric power supply, suitable for voltage input of different countries.

l Power twist power input and output

l Input Voltage: AC88 ～ 256V 50/60Hz

l Dimension: 19\" 1U, 482mm ×168mm ×44mm

l Net Weight: 1.7Kg

Product Overview ：

l POWER indicator: shows the OFF / ON status .

l Eth. 1 indicator: shows the connection status of Ethernet 1.

l Eth. 2 indicator: shows the connection status of Ethernet 2.

l DMX 1-8 indicators: show the status of DMX ports.

l TFT display: shows the current status or menu.

l Function Buttons:

l RETURN button: used to return the previous menu.

l UP button: used to select item of submenu.

l DOWN button: used to select item of submenu.

l ENTER button: used to confirm the item.

l Power switch: turn on or turn off the unit.

l AC IN: used to input the AC voltage to the unit.

l AC OUT : used to output the AC voltage to the next unit.

l DMX ports 1-8: used to input/output standard DMX 512 signal.

l Ethernet 2 port: used to input/output Ethernet signal.

l Ethernet 2 indicator: shows the connection status of Ethernet 2.

l Ethernet 1 indicator: shows the connection status of Ethernet 1.

l Ethernet 1 port: used to input/output Ethernet signal.

Notes: Ethernet 1 and Ethernet 2 ports are switch communication modes, which can used to connect to the next converter.
