S600 Genus 1000W framing moving heads

Product Parameters:

Input Voltage: 100-240V, 50/60Hz

Power consumption: 1050W

Power supply: 1200W

Light source: 1000W Module LED Engine

Lifetime:≥20,000Hours

Color temperature: 7500K

Linear CTO color temperature adjustment (3000K-7000K)

Standard color rendering index Ra ≥ 70

High color rendering index Ra ≥ 90

Beam angle: 5°-50°

Linear CMY color mixing system

Color wheel: 1 color wheel, 6 fixed colors+CRI color that can be rotated in both directions

Fixed Gobo : 1 fixed gobo ,9 fixed gobo

Rotation Gobo: 1 rotating gobo , 7 Rotation Gobo, patterns can be replaced

Animation gobo, imitating water patterns and flame effects, dynamic disc rotatable

Prism:4-prism,4-sided straight mirror, both capable of bi-directional rotation

Two independent frost tablets (Mild and moderate) can be used in combination

Cutting system: 4 grating to achieve fast and smooth cutting, each grating cutting direction and Angle can be independently controlled; The entire cutting module can be rotated 120°

0-100% 16bit smooth dimming(Four dimming modes)

Adjustable refresh frequency, HD camera shooting without flicker

More strobe effects, variable speed

DMX Channel: 22/30/31/39/40CH

Operate mode: DMX512, master/slave

Electronic autofocus

Outstanding strobe effect with variable speed

Control panel: LCD touch screen

Intelligent protection of overheat temperature

X-axis rotation angle: 540°

Y-axis rotation angle: 270°

P/T: 16 bit precision scanning, no deviation

XY axis magnetic coding positioning is more accurate

Three phase motor with SY Brand

Signal socket: standard 3-pin XLR and 5-pin XLR socket or RJ45

Standard with 50MM folding fixture

Fixture size: 442x308x730mm

Protection level: IP65

Net weight: 38.KG

Product Features:

fixture set light beam, spot, wash and cutting functions in one, pure color, uniform spot, color plate, glass gobo plate, CTO, CRI plate are schott materiallt, , Plug in CMY color system, Provides rich color saturation and clear seamless color transitions. LED adopts energy-saving and environment-friendly 1000W monochrome LED light engine, which can produce extremely high light output white light, color temperature of 7500K, CRIRA≥90, and zoom range 6°- 50,The cutting system consists of 4 gratings, which can be rotated ± 60°, giving designers unlimited spot creativity. Two high brightness atomizing pieces of new materials can be respectively inserted and superimposed,All day use, waterproof rating IP65
